HDX Commercial Series

Stop the fouling, lower your costs, and save time, all while increasing efficiency and performance


Hull Shield's HDX Series meets the demand for more power and robust ultrasonic antifouling solutions that can protect valuable marine assets from biofouling.  Our HDX systems provide the highest unit transfer of ultrasound power in the industry, delivering greater range and penetration when compared to anything else avaialble.

HALTS FOULING | MITIGATES RISK | REDUCES DAMAGE | INCREASES EFFICIENCY | BOOSTS PERFORMANCE

SEAYa! Marine specializes in designing the highest quality antifouling solutions for the maritime industry.  SEAYa! Marine is equipped to put together the optimal layout, design and installation of Hull Shield HDX Commercial Series Antifouling Systems in any commercial vessel or Super Yacht.

DNR - Police  -  Fire & Rescue
Coast Guard  -  Naval Ships  -  Government
Tow Boats  -  Tug Boats
Fishing Vessels  -  Cargo Vessels
Commercial Charter Vessels
Yachts & Super Yachts

DNR and Coast Guard Center Console Vessels, to 250' Super Yacht's, to Commercial Cargo Ships we can assist with the ultimate antifouling solution for your vessel.


Hulls
Shafts & Props
Jet Drives
Steering & Control Gear
Sea Chests & Box Coolers
Pipework & Valves
Keel Coolers
Heat Exchangers & RSW Cooling
Diesel & Water Tank Storage

Hull Shield HDX systems can protect hulls, props, shafts, jet-drives, pods, steerage, control gear, sea chests, box coolers, pipework, keel coolers, heat exchangers, RSW cooling systems, bulk storage tanks.  By using Hull Shield HDX systems, marine operators can enjoy the benefits of reduced fuel consumption, lower emissions, improved performance, more responsive and safter handling, extended service intervals, and increased asset lifespan.

PROTECTING YOUR ASSETS

Reducing the risk of downtime is critical when money is on the line.  Hull Shield HDX product help protect your assets inside and out.

HDX ultrasonic antifouling systems can be leveraged to add additional layers of protection to a divers antifouling regime, or conversely, systems can replace existing biofouling prevention methods to provide a more sustainable and ecological long-term solution.

HDX-8

Industrial Ultrasonic Antifouling

The Hull Shield HDX-8 is the flagship of the series and can control up to eight (8) transducers.

Includes 100m of signal cable.

POWER              60W (2.5A @ 24V)
DIMENSIONS    11.24″H x 13.74″W x 5.72″D
WEIGHT             8.44lbs (3.83kg)


HDX-4

Industrial Ultrasonic Antifouling

The Hull Shield HDX-4 is the flagship of the series and can control up to four (4) transducers.

Includes 100m of signal cable.

POWER              30W (1.25A @ 24V)
DIMENSIONS    9.04”H x 11.04″W x 3.72″D
WEIGHT             6.17lbs (2.80kg)


HDX-2

Industrial Ultrasonic Antifouling

The Hull Shield HDX-2 is the flagship of the series and can control up to two (2) transducers.

Includes 100m of signal cable.

POWER              60W (2.5A @ 24V)
DIMENSIONS    7.04”H x 9.04”W x 5.22”D
WEIGHT             4.28lbs (1.94kg)


HDX Series Technical Details

OPERATING CHARACTERISTICS

Maximum Input Voltage              36.0V
Operating Voltage Range            24.0V to 28.0V
Output Voltage Range (VAC)      230V to 280V (RMS)
Operating Temperature               -22F to 140F (-30C to 60C)


FREQUENCY & PULSE

Frequency Range                       22,727 Hz to 41,666 Hz
MAX Sustained Pulse Power   72 Watts
Peak Pulse Power (<1ms)        90 Watts


RATINGS

Enclosure                                 IP68, NEMA 6P,12; UL94 V-0; UL746C 5VA
Signal Connectors                  IP67; IP68; UL94 V-0
Rocker Switch                          IP67, RoHS-3
Power/Auxiliary Cable           UL2464; VW-1; 80C; RoHS



Industry Best Warranty

Hull Shield offers an industry first lifetime warranty on its products.

Warranty is provided to the original purchaser and does not transfer with ownership change of the vessel.  Contact sales for full warranty program details.

Installation Services

SEAYa! Marine offers installation services throughout the Mid-Atlantic from Virginia to New Jersey.  Let our experienced team get the job done right for you.

Self Installation - for those who are DIY or have on-staff labor email technical support is provided with every purchase.
